Features

• Finish: Black
• Power: 18.5W
• Input: 48 VDC
• Color Temperature:2700K, 3000K, 3500K, 4000K
• Delivered Lumens: 1220
• CRI: 90
• ELV Dimming: 100-0.1%
• 0-10V Dimming: 100-0.1%
• TRIAC Dimming: 100-0.1%
• Beam: 100
• Rated Life: 50000 Hours
• Construction: Extruded aluminum with polycarbonate endcaps and lens
• Provides high lumen output linear line of light
• To enable access to VENTRIX element releasing tabs, maintain at least 3 of free channel space
• Driver concealed within the fixture
• Can be mounted on ceiling or wall vertically or horizontally

Dimensions

• Length: 24″
• Width: 1.5″
• Height: 1.75″

Documents

• Spec Sheet
• Instruction Sheet
