The Sapphire II COB Series is an architectural grade LED high lumen downlight. The Sapphire II uses the latest COB technology by Cree. The COB allows for better optic control offering 3 beam spreads. Beam spreads focus the light down to the work plane from high ceiling applications.

Features:

• Housing sold separately
• Wattage/ Lumens: 18W/ 1500 lm
• Color Temperature: 2700K, 3000K, 3500K, 4000K
• Beam Spread: Spot, Narrow Flood, Flood
• Driver: 120-277V Input; 0-10V dimming
• Reflector Finish: Black, Clear Diffused, Haze, White
• Flange Finish: Self Flanged
• Over 80% energy savings when compared to incandescent
• Reflector assembly is compatible with Nora 8 Commercial and Architectural Frames.

Dimensions:

• Diameter:9″
• Height:9-1/4“
• Cutout:8″ to8-3/4″

Lamping:

• 18W LED, 1500 lm

Documents:

• Spec Sheet
• Instruction Sheet
