A simple, sophisticated smart fan that works seamlessly in transitional, minimalist and other modern environments, Axis is perfectly sized for medium-sized kitchens, bedrooms and living rooms, and its wet-rated status and weather-resistant finish make it prime for outdoor use as well.

Features

• Finish/Blades:
  • Bronze with Bronze
  • Matte Black with Matte Black
  • Matte White with Matte White
• Construction: Aluminum, ABS
• Voltage: 120V
• Blade Pitch: 14
• Mounting Slope:Up to 30
• Three blades
• Total Power: 52.5W
• 6 fan speeds through both Summer and Winter Modes
• Modern Forms Fans pair with the smart home tech you know and love, including Google Assistant, Amazon Alexa, Samsung Smart Things, Ecobee, Control 4, and Josh.ai
• Integrates with smart home devices you already own, including Google Assistant, Amazon Echo, Nest & ecobee for voice command and energy savings
• Bluetooth remote control included (Part# F-RCBT-WT). Optional wall switches are available for 3 or 4 way setup (Part# F-WCBT-WT)sold separately
• Additional battery-operated Bluetooth hand-held remotes are available (Part # F-RCBT-WT)sold separately
• Silent DC motor runs 70% more energy efficient than traditional AC motors

Airflow/Energy Efficiency

• Weighted-Average/High Airflow CFM: 3896/5695
• Weighted-Average/High Energy Use (W): 13/33
• Estimated Yearly Energy Cost ($): 6
• Weighted-Average/High Efficiency (CFM/W): 211/153
• Max RPM:167

Dimensions

• Blade Sweep: 52″
• Height:15″
• Downrod: 1″ O.D. x 4.5″H inlcuded
• Wire: 80″
• Motor Type: 125 x 20 sensorless DC motor
• Hanging Weight:13.5 lbs

Lamping

• 19.5WIntegrated LED (Included)
• Color Temperature: 2700K, 3000K, 3500K
• Lumens/Delivered Lumens: 1600/708
• CRI: 90
• Rated Life:50,000 hours

Documents

• Spec Sheet
• Instruction Sheet
