The R620L Series 15W Adjustable Beam LED Cylinder is an economical and affordable trac fixture, with a simple and timeless cylindrical aesthetic.

Features

• Finish: Black, Silver, White
• Mounting Adapter Type: Juno Universal 120V Trac Adapter
• Wattage: 15W
• Voltage: 120V
• Color Temperature:2700K, 3000K, 3500K, 4000K
• Lumens: Up to1234
• CRI: 90
• Dimming Compatibility:Phase Dimmable
• Distribution:Variable Beam System
• Aiming:360 horizontal coverage
• 95 vertical aiming capability
• Compatible with either Juno trac systems
• Universally compatible with both Trac-Master 1-circuit or 2-circuit trac, Trac-Lites trac, monopoints and special mountings
• Also UL Recognized for use on ConTech LT Series track
• Copper alloy contacts provide precise spring action no arcing and will not take a set
• True, positive electrical ground
• On /off switch included
• Patented embossed polarity arrows on bottom of adapter
• Springloaded positive latch with embossed polarity arrows secures trac light to trac
• Two-position power contact provided for two-circuit application

Dimensions

• Diameter: 3″
• Height: 8.31″

Lamping

• 1 x 15W LED

Documents

• Spec Sheet
