CSL320series is an architectural LED Luminaire with direct/indirect light distributions. Offered in three lumen output options up to 1110 Lumens per Ft., and a patented frosted lens to eliminate any hot spots for a uniform beam of light. Manufactured from extruded aluminum with three standard powder-coated color options makes this low profile luminaire ideal for retail, office, school or commercial applications.

Features

• Type:Suspended mount
• Power/Lumens (per ft): 3.75W/555 lm, 5.25W/777 lm, 7.5W/1110 lm
• Color Temperature: 3500K
• Finish; White, Black, Silver
• Voltage: 120-277V
• Mounting:12Ft. Cable
• Driver:1% 0-10V dimming
• Frosted Lens
• CRI: 90+

Dimensions

• Length:45″
• Width: 2.68″
• Height: 3.55″

Document

• Spec Sheet
• Instruction Sheet
